Introduction:
The glass fibre paint mist felt is made of high quality glass fibre, which is a green and white environmentally friendly filter material; the fibre filaments are fine, arranged in a uniform and orderly manner, and gradually encrypted structure. The windward side is green and the outgoing side is white.
The low compression performance keeps its shape unchanged, which makes its filter fibre completely conducive to the storage of oil mist dust. During operation, the glass fibre paint barrier mesh generates static electricity by friction with the pressurized air, which efficiently absorbs the excessive free particles of spray paint generated during operation and reduces the pollution to the environment.
| Frame material | Aluminium or galvanised frame |
Filter material | Made of highly elastic, fracture-resistant glass fibre with an increasing fibre structure. |
Efficiency | G3,G4,M5 |
Temperature resistance | 170℃ |
Applications | Pre-filtration for air conditioning and painting systems, paint spraying systems and workshops |
Technical Parameters:
External Dimensions (mm) | Rated air volume (m3/h) | Initial pressure loss (Pa) |
290*595*46 | 3400 | 135 |
490*595*46 | 2000 | 135 |
595*595*46 | 1500 | 85 |
Features:
Made of long glass fibres in a non-textile way, with high air permeability, low resistance and good efficiency in capturing paint mist.
High-strength glass fibre incremental structure, the air inlet side is green, the air outlet side is white.
Low compression properties to keep the paint mist mat appearance unchanged, so that its filter fibres are completely conducive to the storage of oil mist dust.
Flame resistant. Temperature resistance 170℃.
Suitable for a variety of industrial uses, such as pollution control, air conditioning, electronics, pharmaceuticals, food industry, public construction, etc.
Applications:
High-quality paint mist filtration for surface spraying with high capture rates. Highly efficient absorption of excessive free ions generated during spraying of paint, balancing the pressure in the workspace, a typical environmentally friendly material.
Paint blocking cotton traps paint mist in paint spray booths and paint spraying equipment systems or adsorbs fumes in kitchens and chemical systems, so that the emission gas meets environmental requirements.
